演示 | 高密度、双转换在线电源保护,具有可扩展的运行时间。 |
---|---|
主输入电压 | 230 V 400 V 3 相 |
---|---|
其他输入电压 | 220V 240V 380V 415V |
主输出电压 | 230V |
其他输出电压 | 220V 240V |
额定功率(W) | 10000 W |
额定功率(VA) | 10000 VA |
输出连接类型 | 6 IEC 60320 C13 3 IEC 跳线 4 IEC 60320 C19 |
输出连接器类型 | 硬线 3 线 (H N + E) 1 |
电池类型 | 铅酸电池 |
提供的设备 | 含软件 CD 文档 CD 安装指南 温度探头 USB 电缆 保修卡 Web/SNMP 管理卡 |
产品网络子系列 | 高密度 |
---|---|
电源模块空闲槽位数 | 0 |
电源模块填充槽位数 | 0 |
冗余 | 否 |
颜色 | 黑色 |
---|---|
高度 | 43.2 厘米 |
宽度 | 26.3 厘米 |
深度 | 71.5 厘米 |
净重 | 111.82 千克 |
安装位置 | 前 |
安装首选项 | 无偏好 |
安装模式 | 机架安装式套件 |
可安装两个柱 | 0 |
USB 兼容 | 是 |
网络频率 | 40...70 Hz 自动感应 |
---|---|
输入连接器数量 | 1 根硬线 3 线 (1P + N + E) 1 根硬线 5 线 (3P + N + E) |
输入电压限制 | 100...275 V 可调(半负载) 173...476 V 可调(半负载) |
最大可配置功率(W) | 10000 W |
---|---|
谐波失真 | 小于 2 % |
输出频率 | 50/60 Hz +/- 3 Hz 与电源同步 |
波峰因数 | 3 : 1 |
UPS 类型 | 在线双重转换 |
波形类型 | 正弦波 |
旁路类型 | 内部旁路(自动和手动) |
最大可配置功率(VA) | 10000 VA |
产品认证 | CE EAC IRAM RCM VDE |
---|---|
标记 | CE 标志 |
标准 | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
运行环境空气温度 | 0…40 °C |
---|---|
相对湿度 | 0…95 % |
工作高度 | 0...10000 英尺 |
存储环境空气温度 | -15…45 °C |
存储相对湿度 | 0…95 % 非冷凝 |
存储海拔 | 0.00…15240.00 米 |
声级 | 55 dBA |
散热 | 1947 Btu/h |
IP 防护等级 | IP20 |
电池已充满的插槽数量 | 0 |
---|---|
电池充电时间 | 1。5 小时 |
电池更换数量 | 2 |
电池电压 | +/- 192 V(分体电池以中性线为基准) |
电池充电器功率 | 876 W 额定值 |
电池电量(VAH) | 1805 VAh 运行时间 |
电池寿命 | 3…5 年 |
电池选项 | SRT192BP2 1 3610 VAh SRT192BP2 2 5415 VAh SRT192BP2 3 7220 VAh SRT192BP2 4 9025 VAh SRT192BP2 5 10830 VAh SRT192BP2 6 12635 VAh SRT192BP2 8 16245 VAh SRT192BP2 10 19855 VAh |
延长运行时间 | 1 |
空闲插槽 | 1 |
---|---|
警报 | 声音和视觉警报:按严重程度划分优先级 |
紧急断电 | 是 |
浪涌能量率 | 480 J |
---|
包装 1 的单位类型 | PCE |
---|---|
包装 1 中的单位数量 | 1 |
封装 1 高度 | 46.1 厘米 |
封装 1 宽度 | 60 厘米 |
封装 1 长度 | 100 厘米 |
包裹 1 重量 | 126.554 千克 |
保修 | 3 年维修或更换(不包括电池)和 2 年电池 |
---|
